The Series Regulators are intended for primary as well as Secondary guses or as point of use pressore control in high Purity gas distribution systems.
| Single stage |
| Chrome Plated forged brass body with basic layer of copper. |
| PTFE & Neoprene Material Diaphragm enhancing gas Parity greatly as well as offer very sensitive pressure control on Gus. |
| 5 Port configuration on each body of regulator. |
| Bulk co2 gas distribution Systems. |
| Capsule Seat Teflon - Increased Serviceability and life. |
100% lead free brass material - Economical high purity design |
| Capsule Seat Teflon
- Increased Serviceability and life. |
Chrome plated forged brass body - Corrosion resistance - Increased long – life service |
| PTFE & Neoprene Diaphragm.
- PTFE Offer very high purity of gas. - Neoprene deliver very Sensitive pressure control on gas. |
High Flow Capacity - Supply multiple user locations. |
| Forged Body
- Durable, long – lasting construction. |
280 bar inlet pressure plating. - Safe use with high pressure cylinders. |
| Large convoluted Diaphragm - Smooth pressure changes |
|
| Standard Relief Value. - Diaphragm and gauge protection |
| Body | Chrome – plated forged brass. |
| Bonnet | Chrome – plated forged brass. / Plastic. |
| Seat | PTFE capsule Seat. |
| Filter | 10 Micron sintered bronze |
| Diaphragm | PTFE + Neoprene |
| Spring | 316 Stainless steel |
| Internal Seals | PTFE |
| Max inlet pressure | 280 Dar. / 140 bar |
| Temperature Range | 40C to 60C |
| Gouge | 2” diameter |
| Port thread | ¼ BSP or ¼ NPT |
| Weight |
